Grace 6 Column 485mm, 20 sections

From: £1,219.92

  • 485mm tall, 1234mm long, 254mm deep.
  • Heat output (ΔT50): 1776 Watts
  • Heat output (ΔT50): 6060 BTUs
  • Weight: 134 kg
  • Guarantee: 10 years
  • Delivered in: 7-8 weeks
  • Delivered in 2 pieces for partial home assembly. You will need to hire an Assembly Toolkit with purchase of this radiator.

Configure Radiator

Grace 6 Column 485mm, 20 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 485mm
(D) Depth 254mm
(L) Length 1234mm
(PC) Pipe centres 1324mm
(TS) Total space required 1414mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 1776 Watts
Empty weight 136kg
Internal volume 17 L
Delivery 1 piece
Maximum operating pressure 8 bar
Weight 136 kg
Dimensions 1234 × 254 × 485 mm
Number of sections

20

Internal volume

17

Length (mm)

1234

Certification

EN442

Height (mm)

485

Construction material

Cast iron

Depth (mm)

254

Made in

England

Heat output (ΔT50) Watts

1776

Heat Output (ΔT50) BTUs

6060

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1090_g6c_485
