Grace 6 Column 485mm

From: £313.20

Product Description
SKU: CI-G6C-485

Model Specifications

Label Attribute Value
A Height With Legs (mm) 500
B Bottom Inlet To Floor (mm) 105
C Max Section Depth (mm) 255
- Output (ΔT50, W) 88.8
- Output (ΔT30, W) 46.4
D Interaxis Distance (mm) 350
E Height Without Legs (mm) 450
F Section Length (mm) 60.5
G Mid Section Depth (mm) 221
- Internal Volume (L) 0.7
- Empty Leg Section Weight (kg) 7.1
- Empty Mid Section Weight (kg) 7.3
- Factor, Km 0.6181
- Exponent, n 1.2698
Grace 6 Column 485mm - Single Section Technical Drawing - SVG

Sizes Available

83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
83731
SKU N
Secs
Length
(L, mm)
Output
(∆T50, Watts)
Output
(∆T30, Watts)
Delivery
pieces
Price
from
CI-G6C-485-3 3 211 266 139 1 £313.20
CI-G6C-485-4 4 272 355 185 1 £363.60
CI-G6C-485-5 5 332 444 232 1 £414.00
CI-G6C-485-6 6 393 532 278 1 £464.40
CI-G6C-485-7 7 453 621 324 1 £514.80
CI-G6C-485-8 8 514 710 371 1 £565.20
CI-G6C-485-9 9 574 799 417 1 £615.60
CI-G6C-485-10 10 635 888 464 1 £666.00
CI-G6C-485-11 11 695 976 510 1 £716.40
CI-G6C-485-12 12 756 1065 556 1 £766.80
CI-G6C-485-13 13 816 1154 603 1 £817.20
CI-G6C-485-14 14 877 1243 649 1 £867.60
CI-G6C-485-15 15 937 1332 696 1 £918.00
CI-G6C-485-16 16 998 1420 742 2 £1,052.40
CI-G6C-485-17 17 1058 1509 788 2 £1,102.80
CI-G6C-485-18 18 1119 1598 835 2 £1,153.20
CI-G6C-485-19 19 1179 1687 881 2 £1,203.60
CI-G6C-485-20 20 1240 1776 928 2 £1,254.00
CI-G6C-485-21 21 1300 1864 974 2 £1,304.40
CI-G6C-485-22 22 1361 1953 1020 2 £1,354.80
CI-G6C-485-23 23 1421 2042 1067 3 £1,405.20
CI-G6C-485-24 24 1482 2131 1113 3 £1,455.60
CI-G6C-485-25 25 1542 2220 1160 3 £1,506.00
CI-G6C-485-26 26 1603 2308 1206 3 £1,556.40
CI-G6C-485-27 27 1663 2397 1252 3 £1,606.80
CI-G6C-485-28 28 1724 2486 1299 3 £1,657.20
CI-G6C-485-29 29 1784 2575 1345 3 £1,707.60
CI-G6C-485-30 30 1845 2664 1392 3 £1,758.00
CI-G6C-485-31 31 1905 2752 1438 3 £1,808.40
CI-G6C-485-32 32 1966 2841 1484 3 £1,858.80
CI-G6C-485-33 33 2026 2930 1531 3 £1,909.20
CI-G6C-485-34 34 2087 3019 1577 3 £1,959.60
CI-G6C-485-35 35 2147 3108 1624 3 £2,010.00
CI-G6C-485-36 36 2208 3196 1670 3 £2,060.40
CI-G6C-485-37 37 2268 3285 1716 3 £2,110.80
CI-G6C-485-38 38 2329 3374 1763 3 £2,161.20
CI-G6C-485-39 39 2389 3463 1809 3 £2,211.60
CI-G6C-485-40 40 2450 3552 1856 3 £2,262.00
Grace 6 Column 485mm - 10 Section Battery Technical Drawing - SVG
