Rococo II 510mm
Cast Iron · by Castrads
From: £375.60
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
An ornate cast iron radiator, faithfully reproduced from an American Radiator Company original.
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 14 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 5-6 weeks lead time
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 510 |
| E | Height Without Legs (mm) | 451 |
| - | Empty Leg Section Weight (kg) | 8.8 |
| - | Empty Mid Section Weight (kg) | 7.8 |
| B | Bottom Inlet To Floor (mm) | 114 |
| C | Max Section Depth (mm) | 220 |
| G | Mid Section Depth (mm) | 179 |
| D | Interaxis Distance (mm) | 350 |
| F | Section Length (mm) | 78.3 |
| - | Output (ΔT50, W) | 77.5 |
| - | Output (ΔT30, W) | 40.7 |
| - | Internal Volume (L) | 1.8 |
| - | Exponent, n | 1.2608 |
| - | Factor, Km | 0.5592 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| CI-RC2-510-3 | 3 | 264 | 233 | 122 | 1 | £375.60 |
| CI-RC2-510-4 | 4 | 343 | 310 | 163 | 1 | £432.00 |
| CI-RC2-510-5 | 5 | 421 | 388 | 204 | 1 | £488.40 |
| CI-RC2-510-6 | 6 | 499 | 465 | 244 | 1 | £544.80 |
| CI-RC2-510-7 | 7 | 578 | 543 | 285 | 1 | £601.20 |
| CI-RC2-510-8 | 8 | 656 | 620 | 326 | 1 | £657.60 |
| CI-RC2-510-9 | 9 | 734 | 698 | 367 | 1 | £714.00 |
| CI-RC2-510-10 | 10 | 813 | 776 | 407 | 1 | £770.40 |
| CI-RC2-510-11 | 11 | 891 | 853 | 448 | 1 | £826.80 |
| CI-RC2-510-12 | 12 | 969 | 931 | 489 | 1 | £883.20 |
| CI-RC2-510-13 | 13 | 1047 | 1008 | 529 | 1 | £939.60 |
| CI-RC2-510-14 | 14 | 1126 | 1086 | 570 | 1 | £996.00 |
| CI-RC2-510-15 | 15 | 1204 | 1163 | 611 | 2 | £1,140.00 |
| CI-RC2-510-16 | 16 | 1282 | 1241 | 652 | 2 | £1,196.40 |
| CI-RC2-510-17 | 17 | 1361 | 1318 | 692 | 2 | £1,252.80 |
| CI-RC2-510-18 | 18 | 1439 | 1396 | 733 | 2 | £1,309.20 |
| CI-RC2-510-19 | 19 | 1517 | 1474 | 774 | 2 | £1,365.60 |
| CI-RC2-510-20 | 20 | 1596 | 1551 | 815 | 2 | £1,422.00 |
| CI-RC2-510-21 | 21 | 1674 | 1629 | 855 | 2 | £1,478.40 |
| CI-RC2-510-22 | 22 | 1752 | 1706 | 896 | 3 | £1,534.80 |
| CI-RC2-510-23 | 23 | 1830 | 1784 | 937 | 3 | £1,591.20 |
| CI-RC2-510-24 | 24 | 1909 | 1861 | 978 | 3 | £1,647.60 |
| CI-RC2-510-25 | 25 | 1987 | 1939 | 1018 | 3 | £1,704.00 |
| CI-RC2-510-26 | 26 | 2065 | 2017 | 1059 | 3 | £1,760.40 |
| CI-RC2-510-27 | 27 | 2144 | 2094 | 1100 | 3 | £1,816.80 |
| CI-RC2-510-28 | 28 | 2222 | 2172 | 1140 | 3 | £1,873.20 |
| CI-RC2-510-29 | 29 | 2300 | 2249 | 1181 | 3 | £1,929.60 |
| CI-RC2-510-30 | 30 | 2379 | 2327 | 1222 | 3 | £1,986.00 |
| CI-RC2-510-31 | 31 | 2457 | 2404 | 1263 | 3 | £2,042.40 |
| CI-RC2-510-32 | 32 | 2535 | 2482 | 1303 | 3 | £2,098.80 |
| CI-RC2-510-33 | 33 | 2613 | 2559 | 1344 | 3 | £2,155.20 |
| CI-RC2-510-34 | 34 | 2692 | 2637 | 1385 | 3 | £2,211.60 |
| CI-RC2-510-35 | 35 | 2770 | 2715 | 1426 | 4 | £2,268.00 |
| CI-RC2-510-36 | 36 | 2848 | 2792 | 1466 | 4 | £2,324.40 |
| CI-RC2-510-37 | 37 | 2927 | 2870 | 1507 | 4 | £2,380.80 |
| CI-RC2-510-38 | 38 | 3005 | 2947 | 1548 | 4 | £2,437.20 |
| CI-RC2-510-39 | 39 | 3083 | 3025 | 1588 | 4 | £2,493.60 |
| CI-RC2-510-40 | 40 | 3162 | 3102 | 1629 | 4 | £2,550.00 |
