Grace 4 Column 660mm, 6 sections

From: £421.20

  • 660mm tall, 391mm long, 175mm deep.
  • Heat output (ΔT50): 512 Watts
  • Heat output (ΔT50): 1746 BTUs
  • Weight: 32 kg
  • Guarantee: 10 years
  • Delivered in: 6 weeks
  • Delivered ready for installation

Configure Radiator

Grace 4 Column 660mm, 6 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height mm
(D) Depth mm
(L) Length mm
(PC) Pipe centres
(TS) Total space required
Open pipe centre measurements document for more information.
Heat output (ΔT50) Watts
Empty weight
Internal volume L
Delivery 1 piece
Maximum operating pressure
Weight 32.0 kg
Dimensions 391 × 175 × 660 mm
Number of sections

6

Internal volume

5.1

Length (mm)

391

Certification

EN442

Height (mm)

660

Construction material

Cast iron

Depth (mm)

175

Made in

England

Heat output (ΔT50) Watts

512

Heat output (ΔT50) BTUs

1746

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1087_g4c_660
