Grace 4 Column 500mm, 18 sections

From: £861.07

  • 504mm tall, 1114mm long, 175mm deep.
  • Heat output (ΔT50): 1166 Watts
  • Heat output (ΔT50): 3980 BTUs
  • Weight: 83 kg
  • Guarantee: 10 years
  • Delivered in: 6 weeks
  • Delivered ready for installation

Configure Radiator

Grace 4 Column 500mm, 18 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 504mm
(D) Depth 175mm
(L) Length 1114mm
(PC) Pipe centres 1204mm
(TS) Total space required 1294mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 1166 Watts
Empty weight 84kg
Internal volume 0 L
Delivery 1 piece
Maximum operating pressure 0
Weight 84 kg
Dimensions 1114 × 175 × 504 mm
Number of sections

18

Internal volume

9.18

Length (mm)

1114

Certification

EN442

Height (mm)

504

Construction material

Cast iron

Depth (mm)

175

Made in

England

Heat output (ΔT50) Watts

1166

Heat output (ΔT50) BTUs

3980

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1086_g4c_500
