Florence 4 Column 1000mm
Steel · by Castrads
From: £358.80
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install
- Heat pump compatible
- 10 year warranty
- Not suitable for steam
- Welded joins with powder coat finish
- Made in Italy
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 1102 |
| E | Height Without Legs (mm) | 1002 |
| - | Empty Leg Section Weight (kg) | 3 |
| - | Empty Mid Section Weight (kg) | 2.7 |
| B | Bottom Inlet To Floor (mm) | 134 |
| C | Max Section Depth (mm) | 141 |
| G | Mid Section Depth (mm) | 139 |
| D | Interaxis Distance (mm) | 935 |
| F | Section Length (mm) | 45 |
| - | Output (ΔT50, W) | 125.9 |
| - | Output (ΔT30, W) | 63.5 |
| - | Internal Volume (L) | 1.92 |
| - | Exponent, n | 1.34023 |
| - | Factor, Km | 0.6653 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| SMC-F4C-1002-3 | 3 | 161 | 378 | 190 | 1 | £358.80 |
| SMC-F4C-1002-4 | 4 | 206 | 504 | 254 | 1 | £417.60 |
| SMC-F4C-1002-5 | 5 | 251 | 630 | 317 | 1 | £476.40 |
| SMC-F4C-1002-6 | 6 | 296 | 755 | 381 | 1 | £535.20 |
| SMC-F4C-1002-7 | 7 | 341 | 881 | 444 | 1 | £594.00 |
| SMC-F4C-1002-8 | 8 | 386 | 1007 | 508 | 1 | £652.80 |
| SMC-F4C-1002-9 | 9 | 431 | 1133 | 571 | 1 | £711.60 |
| SMC-F4C-1002-10 | 10 | 476 | 1259 | 635 | 1 | £770.40 |
| SMC-F4C-1002-11 | 11 | 521 | 1385 | 698 | 1 | £829.20 |
| SMC-F4C-1002-12 | 12 | 566 | 1511 | 762 | 1 | £888.00 |
| SMC-F4C-1002-13 | 13 | 611 | 1637 | 825 | 1 | £946.80 |
| SMC-F4C-1002-14 | 14 | 656 | 1763 | 889 | 1 | £1,005.60 |
| SMC-F4C-1002-15 | 15 | 701 | 1889 | 952 | 1 | £1,064.40 |
| SMC-F4C-1002-16 | 16 | 746 | 2014 | 1016 | 1 | £1,123.20 |
| SMC-F4C-1002-17 | 17 | 791 | 2140 | 1079 | 1 | £1,182.00 |
| SMC-F4C-1002-18 | 18 | 836 | 2266 | 1143 | 1 | £1,240.80 |
| SMC-F4C-1002-19 | 19 | 881 | 2392 | 1206 | 1 | £1,299.60 |
| SMC-F4C-1002-20 | 20 | 926 | 2518 | 1270 | 1 | £1,358.40 |
| SMC-F4C-1002-21 | 21 | 971 | 2644 | 1333 | 1 | £1,417.20 |
| SMC-F4C-1002-22 | 22 | 1016 | 2770 | 1397 | 1 | £1,476.00 |
| SMC-F4C-1002-23 | 23 | 1061 | 2896 | 1460 | 1 | £1,534.80 |
| SMC-F4C-1002-24 | 24 | 1106 | 3022 | 1524 | 1 | £1,593.60 |
| SMC-F4C-1002-25 | 25 | 1151 | 3148 | 1587 | 1 | £1,652.40 |
| SMC-F4C-1002-26 | 26 | 1196 | 3273 | 1651 | 1 | £1,711.20 |
| SMC-F4C-1002-27 | 27 | 1241 | 3399 | 1714 | 1 | £1,770.00 |
| SMC-F4C-1002-28 | 28 | 1286 | 3525 | 1778 | 1 | £1,828.80 |
| SMC-F4C-1002-29 | 29 | 1331 | 3651 | 1841 | 1 | £1,887.60 |
| SMC-F4C-1002-30 | 30 | 1376 | 3777 | 1905 | 1 | £1,946.40 |
| SMC-F4C-1002-31 | 31 | 1421 | 3903 | 1968 | 1 | £2,005.20 |
| SMC-F4C-1002-32 | 32 | 1466 | 4029 | 2032 | 1 | £2,064.00 |
| SMC-F4C-1002-33 | 33 | 1511 | 4155 | 2095 | 1 | £2,122.80 |
| SMC-F4C-1002-34 | 34 | 1556 | 4281 | 2159 | 1 | £2,181.60 |
| SMC-F4C-1002-35 | 35 | 1601 | 4407 | 2222 | 1 | £2,240.40 |
| SMC-F4C-1002-36 | 36 | 1646 | 4532 | 2286 | 1 | £2,299.20 |
| SMC-F4C-1002-37 | 37 | 1691 | 4658 | 2349 | 1 | £2,358.00 |
| SMC-F4C-1002-38 | 38 | 1736 | 4784 | 2413 | 1 | £2,416.80 |
| SMC-F4C-1002-39 | 39 | 1781 | 4910 | 2476 | 1 | £2,475.60 |
| SMC-F4C-1002-40 | 40 | 1826 | 5036 | 2540 | 1 | £2,534.40 |
