• Florence 4 column 765mm curved steel column radiator

Florence 4 Column 765mm

From: £273.00

Product Description
  • Available from 3 to 40 sections long (see below for technical specs)
  • Delivered ready to install
  • Heat pump compatible
  • 10 year warranty
  • Not suitable for steam
  • Welded joins with powder coat finish
  • Made in Italy
SKU: SMC-F4C-767

Model Specifications

Label Attribute Value
A Height With Legs (mm) 867
B Bottom Inlet To Floor (mm) 134
C Max Section Depth (mm) 141
D Interaxis Distance (mm) 700
E Height Without Legs (mm) 767
- Output (ΔT50, W) 98.6
F Section Length (mm) 45
- Output (ΔT30, W) 50.1
G Mid Section Depth (mm) 139
- Internal Volume (L) 1.55
- Empty Leg Section Weight (kg) 2.2
- Empty Mid Section Weight (kg) 1.9
- Factor, Km 0.5556
- Exponent, n 1.32372
Florence 4 Column 765mm - Single Section Technical Drawing - SVG

Sizes Available

83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
83826
SKU N
Secs
Length
(L, mm)
Output
(∆T50, Watts)
Output
(∆T30, Watts)
Delivery
pieces
Price
from
SMC-F4C-767-3 3 165 295 150 1 £273.00
SMC-F4C-767-4 4 210 394 200 1 £318.00
SMC-F4C-767-5 5 255 493 250 1 £363.00
SMC-F4C-767-6 6 300 591 300 1 £408.00
SMC-F4C-767-7 7 345 690 350 1 £453.00
SMC-F4C-767-8 8 390 788 400 1 £498.00
SMC-F4C-767-9 9 435 887 450 1 £543.00
SMC-F4C-767-10 10 480 986 501 1 £588.00
SMC-F4C-767-11 11 525 1084 551 1 £633.00
SMC-F4C-767-12 12 570 1183 601 1 £678.00
SMC-F4C-767-13 13 615 1281 651 1 £723.00
SMC-F4C-767-14 14 660 1380 701 1 £768.00
SMC-F4C-767-15 15 705 1479 751 1 £813.00
SMC-F4C-767-16 16 750 1577 801 1 £858.00
SMC-F4C-767-17 17 795 1676 851 1 £903.00
SMC-F4C-767-18 18 840 1774 901 1 £948.00
SMC-F4C-767-19 19 885 1873 951 1 £993.00
SMC-F4C-767-20 20 930 1972 1002 1 £1,038.00
SMC-F4C-767-21 21 975 2070 1052 1 £1,083.00
SMC-F4C-767-22 22 1020 2169 1102 1 £1,128.00
SMC-F4C-767-23 23 1065 2267 1152 1 £1,173.00
SMC-F4C-767-24 24 1110 2366 1202 1 £1,218.00
SMC-F4C-767-25 25 1155 2465 1252 1 £1,263.00
SMC-F4C-767-26 26 1200 2563 1302 1 £1,308.00
SMC-F4C-767-27 27 1245 2662 1352 1 £1,353.00
SMC-F4C-767-28 28 1290 2760 1402 1 £1,398.00
SMC-F4C-767-29 29 1335 2859 1452 1 £1,443.00
SMC-F4C-767-30 30 1380 2958 1503 1 £1,488.00
SMC-F4C-767-31 31 1425 3056 1553 1 £1,533.00
SMC-F4C-767-32 32 1470 3155 1603 1 £1,578.00
SMC-F4C-767-33 33 1515 3253 1653 1 £1,623.00
SMC-F4C-767-34 34 1560 3352 1703 1 £1,668.00
SMC-F4C-767-35 35 1605 3451 1753 1 £1,713.00
SMC-F4C-767-36 36 1650 3549 1803 1 £1,758.00
SMC-F4C-767-37 37 1695 3648 1853 1 £1,803.00
SMC-F4C-767-38 38 1740 3746 1903 1 £1,848.00
SMC-F4C-767-39 39 1785 3845 1953 1 £1,893.00
SMC-F4C-767-40 40 1830 3944 2004 1 £1,938.00
Florence 4 Column 765mm - 10 Section Battery Technical Drawing - SVG
