Rococo II 510mm, 17 sections

From: £1,129.80

  • 510mm tall, 1354.3mm long, 206.8mm deep.
  • Hydronic output (∆T50°C): 1318 Watts
  • Weight: 108.8kg
  • Warranty: 10 years
  • Delivered in: 8 weeks
  • Delivered in 2 pieces for partial home assembly. During checkout, you will need to hire an Assembly Toolkit with purchase of this radiator.
SKU: CI-RC2-510-17
Build your radiator

Configure Radiator

Rococo II 510mm, 17 sections

Description
Additional information
Product files

Radiator drawing
(H) Height 510mm
(D) Depth 207mm
(L) Length 1354mm
(PC) Pipe centres 1444mm
(TS) Total space required 1534mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 1318 Watts
Empty weight 109kg
Internal volume 28.9 L
Delivery 1 piece
Maximum operating pressure 8 bar
Weight 109 kg
Dimensions 1354 × 207 × 510 mm
Number of sections

17
Internal volume

28.9
Length (mm)

1393
Certification

EN442
Height (mm)

510
Construction material

Cast iron
Depth (mm)

220
Made in

England
Heat output (ΔT50) Watts

1318
Heat Output (ΔT50) BTUs

4495
Maximum operating temperature

95°C for hot water systems
Maximum operating pressure

8 bar
Bleed valve included

Brass or Nickel
Connections

½" BSP as standard
Pipe centres Open document
Declaration of Performance dop-202009-1132_rc2_510
