Grace 6 Column 485mm cast iron radiator - 32 sections (1966mm long) | Castrads
  • £0.00

Grace 6 Column 485mm, 32 sections

From: £1,818.67

  • 500mm tall, 1966mm long, 250.8mm deep.
  • Hydronic output (∆T50°C): 2842 Watts
  • Weight: 233.2kg
  • Warranty: 10 years
  • Delivered in: 8 weeks
  • Delivered in 3 pieces for partial home assembly. During checkout, you will need to hire an Assembly Toolkit with purchase of this radiator.

Configure Radiator

Grace 6 Column 485mm, 32 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 500mm
(D) Depth 251mm
(L) Length 1966mm
(PC) Pipe centres 2056mm
(TS) Total space required 2146mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 2842 Watts
Empty weight 233kg
Internal volume 27.2 L
Delivery 1 piece
Maximum operating pressure 8 bar
Weight 233 kg
Dimensions 1966 × 251 × 500 mm
Number of sections

32

Internal volume

27.2

Length (mm)

1956

Certification

EN442

Height (mm)

485

Construction material

Cast iron

Depth (mm)

254

Made in

England

Heat output (ΔT50) Watts

2842

Heat Output (ΔT50) BTUs

9696

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1090_g6c_485
