Grace 6 Column 485mm
From: £326.40
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 15 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 5-6 weeks lead time
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 500 |
| B | Bottom Inlet To Floor (mm) | 105 |
| C | Max Section Depth (mm) | 255 |
| - | Output (ΔT50, W) | 88.8 |
| - | Output (ΔT30, W) | 46.4 |
| D | Interaxis Distance (mm) | 350 |
| E | Height Without Legs (mm) | 450 |
| F | Section Length (mm) | 60.5 |
| G | Mid Section Depth (mm) | 221 |
| - | Internal Volume (L) | 0.7 |
| - | Empty Leg Section Weight (kg) | 7.1 |
| - | Empty Mid Section Weight (kg) | 6.3 |
| - | Factor, Km | 0.6181 |
| - | Exponent, n | 1.2698 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| CI-G6C-485-3 | 3 | 211 | 266 | 139 | 1 | £326.40 |
| CI-G6C-485-4 | 4 | 272 | 355 | 185 | 1 | £379.20 |
| CI-G6C-485-5 | 5 | 332 | 444 | 232 | 1 | £432.00 |
| CI-G6C-485-6 | 6 | 393 | 532 | 278 | 1 | £484.80 |
| CI-G6C-485-7 | 7 | 453 | 621 | 324 | 1 | £537.60 |
| CI-G6C-485-8 | 8 | 514 | 710 | 371 | 1 | £590.40 |
| CI-G6C-485-9 | 9 | 574 | 799 | 417 | 1 | £643.20 |
| CI-G6C-485-10 | 10 | 635 | 888 | 464 | 1 | £696.00 |
| CI-G6C-485-11 | 11 | 695 | 976 | 510 | 1 | £748.80 |
| CI-G6C-485-12 | 12 | 756 | 1065 | 556 | 1 | £801.60 |
| CI-G6C-485-13 | 13 | 816 | 1154 | 603 | 1 | £854.40 |
| CI-G6C-485-14 | 14 | 877 | 1243 | 649 | 1 | £907.20 |
| CI-G6C-485-15 | 15 | 937 | 1332 | 696 | 1 | £960.00 |
| CI-G6C-485-16 | 16 | 998 | 1420 | 742 | 2 | £1,100.40 |
| CI-G6C-485-17 | 17 | 1058 | 1509 | 788 | 2 | £1,153.20 |
| CI-G6C-485-18 | 18 | 1119 | 1598 | 835 | 2 | £1,206.00 |
| CI-G6C-485-19 | 19 | 1179 | 1687 | 881 | 2 | £1,258.80 |
| CI-G6C-485-20 | 20 | 1240 | 1776 | 928 | 2 | £1,311.60 |
| CI-G6C-485-21 | 21 | 1300 | 1864 | 974 | 2 | £1,364.40 |
| CI-G6C-485-22 | 22 | 1361 | 1953 | 1020 | 2 | £1,417.20 |
| CI-G6C-485-23 | 23 | 1421 | 2042 | 1067 | 3 | £1,470.00 |
| CI-G6C-485-24 | 24 | 1482 | 2131 | 1113 | 3 | £1,522.80 |
| CI-G6C-485-25 | 25 | 1542 | 2220 | 1160 | 3 | £1,575.60 |
| CI-G6C-485-26 | 26 | 1603 | 2308 | 1206 | 3 | £1,628.40 |
| CI-G6C-485-27 | 27 | 1663 | 2397 | 1252 | 3 | £1,681.20 |
| CI-G6C-485-28 | 28 | 1724 | 2486 | 1299 | 3 | £1,734.00 |
| CI-G6C-485-29 | 29 | 1784 | 2575 | 1345 | 3 | £1,786.80 |
| CI-G6C-485-30 | 30 | 1845 | 2664 | 1392 | 3 | £1,839.60 |
| CI-G6C-485-31 | 31 | 1905 | 2752 | 1438 | 3 | £1,892.40 |
| CI-G6C-485-32 | 32 | 1966 | 2841 | 1484 | 3 | £1,945.20 |
| CI-G6C-485-33 | 33 | 2026 | 2930 | 1531 | 3 | £1,998.00 |
| CI-G6C-485-34 | 34 | 2087 | 3019 | 1577 | 3 | £2,050.80 |
| CI-G6C-485-35 | 35 | 2147 | 3108 | 1624 | 3 | £2,103.60 |
| CI-G6C-485-36 | 36 | 2208 | 3196 | 1670 | 3 | £2,156.40 |
| CI-G6C-485-37 | 37 | 2268 | 3285 | 1716 | 3 | £2,209.20 |
| CI-G6C-485-38 | 38 | 2329 | 3374 | 1763 | 3 | £2,262.00 |
| CI-G6C-485-39 | 39 | 2389 | 3463 | 1809 | 3 | £2,314.80 |
| CI-G6C-485-40 | 40 | 2450 | 3552 | 1856 | 3 | £2,367.60 |
