Grace 6 Column 485mm, 24 sections | Castrads
  • £0.00

Grace 6 Column 485mm, 24 sections

From: £1,419.50

  • 485mm tall, 1475mm long, 254mm deep.
  • Heat output (ΔT50): 2131 Watts
  • Heat output (ΔT50): 7272 BTUs
  • Weight: 161 kg
  • Guarantee: 10 years
  • Delivered in: 7-8 weeks
  • Delivered in 3 pieces for partial home assembly. You will need to hire an Assembly Toolkit with purchase of this radiator.

Configure Radiator

Grace 6 Column 485mm, 24 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 485mm
(D) Depth 254mm
(L) Length 1475mm
(PC) Pipe centres 1565mm
(TS) Total space required 1655mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 2131 Watts
Empty weight 162kg
Internal volume 20.4 L
Delivery 1 piece
Maximum operating pressure 8 bar
Weight 162 kg
Dimensions 1475 × 254 × 485 mm
Number of sections

24

Internal volume

20.4

Length (mm)

1475

Certification

EN442

Height (mm)

485

Construction material

Cast iron

Depth (mm)

254

Made in

England

Heat output (ΔT50) Watts

2131

Heat Output (ΔT50) BTUs

7272

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1090_g6c_485
