Mercury 4 Column 460mm
Cast Iron · by Castrads
From: £364.80
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
A cast iron column radiator, exclusive to Castrads, with a refined, symmetrical profile inspired by original designs from the 1920s.
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 18 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 5-6 weeks lead time
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 460 |
| - | Empty Leg Section Weight (kg) | 4.4 |
| - | Empty Mid Section Weight (kg) | 4 |
| B | Bottom Inlet To Floor (mm) | 100 |
| C | Max Section Depth (mm) | 140 |
| - | Output (ΔT50, W) | 58 |
| - | Output (ΔT30, W) | 31 |
| D | Interaxis Distance (mm) | 323 |
| E | Height Without Legs (mm) | 398 |
| F | Section Length (mm) | 58.3 |
| G | Mid Section Depth (mm) | 140 |
| - | Internal Volume (L) | 0.61 |
| - | Factor, Km | 0.4793 |
| - | Exponent, n | 1.2262 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| CI-M4C-460-3 | 3 | 204 | 174 | 93 | 1 | £364.80 |
| CI-M4C-460-4 | 4 | 263 | 232 | 124 | 1 | £417.60 |
| CI-M4C-460-5 | 5 | 321 | 290 | 155 | 1 | £470.40 |
| CI-M4C-460-6 | 6 | 379 | 348 | 186 | 1 | £523.20 |
| CI-M4C-460-7 | 7 | 438 | 406 | 217 | 1 | £576.00 |
| CI-M4C-460-8 | 8 | 496 | 464 | 248 | 1 | £628.80 |
| CI-M4C-460-9 | 9 | 554 | 523 | 279 | 1 | £681.60 |
| CI-M4C-460-10 | 10 | 613 | 581 | 310 | 1 | £734.40 |
| CI-M4C-460-11 | 11 | 671 | 639 | 341 | 1 | £787.20 |
| CI-M4C-460-12 | 12 | 729 | 697 | 372 | 1 | £840.00 |
| CI-M4C-460-13 | 13 | 787 | 755 | 403 | 1 | £892.80 |
| CI-M4C-460-14 | 14 | 846 | 813 | 434 | 1 | £945.60 |
| CI-M4C-460-15 | 15 | 904 | 871 | 466 | 1 | £998.40 |
| CI-M4C-460-16 | 16 | 962 | 929 | 497 | 1 | £1,051.20 |
| CI-M4C-460-17 | 17 | 1021 | 987 | 528 | 1 | £1,104.00 |
| CI-M4C-460-18 | 18 | 1079 | 1045 | 559 | 1 | £1,156.80 |
| CI-M4C-460-19 | 19 | 1137 | 1103 | 590 | 2 | £1,297.20 |
| CI-M4C-460-20 | 20 | 1196 | 1161 | 621 | 2 | £1,350.00 |
| CI-M4C-460-21 | 21 | 1254 | 1219 | 652 | 2 | £1,402.80 |
| CI-M4C-460-22 | 22 | 1312 | 1277 | 683 | 2 | £1,455.60 |
| CI-M4C-460-23 | 23 | 1370 | 1335 | 714 | 2 | £1,508.40 |
| CI-M4C-460-24 | 24 | 1429 | 1393 | 745 | 2 | £1,561.20 |
| CI-M4C-460-25 | 25 | 1487 | 1452 | 776 | 2 | £1,614.00 |
| CI-M4C-460-26 | 26 | 1545 | 1510 | 807 | 2 | £1,666.80 |
| CI-M4C-460-27 | 27 | 1604 | 1568 | 838 | 2 | £1,719.60 |
| CI-M4C-460-28 | 28 | 1662 | 1626 | 869 | 3 | £1,772.40 |
| CI-M4C-460-29 | 29 | 1720 | 1684 | 900 | 3 | £1,825.20 |
| CI-M4C-460-30 | 30 | 1779 | 1742 | 931 | 3 | £1,878.00 |
| CI-M4C-460-31 | 31 | 1837 | 1800 | 962 | 3 | £1,930.80 |
| CI-M4C-460-32 | 32 | 1895 | 1858 | 993 | 3 | £1,983.60 |
| CI-M4C-460-33 | 33 | 1953 | 1916 | 1024 | 3 | £2,036.40 |
| CI-M4C-460-34 | 34 | 2012 | 1974 | 1055 | 3 | £2,089.20 |
| CI-M4C-460-35 | 35 | 2070 | 2032 | 1086 | 3 | £2,142.00 |
| CI-M4C-460-36 | 36 | 2128 | 2090 | 1117 | 3 | £2,194.80 |
| CI-M4C-460-37 | 37 | 2187 | 2148 | 1148 | 3 | £2,247.60 |
| CI-M4C-460-38 | 38 | 2245 | 2206 | 1179 | 3 | £2,300.40 |
| CI-M4C-460-39 | 39 | 2303 | 2264 | 1210 | 3 | £2,353.20 |
| CI-M4C-460-40 | 40 | 2362 | 2322 | 1241 | 3 | £2,406.00 |
