Grace 6 Column 485mm, 35 sections

From: £1,968.36

  • 485mm tall, 2137mm long, 254mm deep.
  • Heat output (ΔT50): 3108 Watts
  • Heat output (ΔT50): 10604 BTUs
  • Weight: 235 kg
  • Guarantee: 10 years
  • Delivered in: 7-8 weeks
  • Delivered in 3 pieces for partial home assembly. You will need to hire an Assembly Toolkit with purchase of this radiator.

Configure Radiator

Grace 6 Column 485mm, 35 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 485mm
(D) Depth 254mm
(L) Length 2137mm
(PC) Pipe centres 2227mm
(TS) Total space required 2317mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 3108 Watts
Empty weight 236kg
Internal volume 29.75 L
Delivery 1 piece
Maximum operating pressure 8 bar
Weight 236 kg
Dimensions 2137 × 254 × 485 mm
Number of sections

35

Internal volume

29.75

Length (mm)

2137

Certification

EN442

Height (mm)

485

Construction material

Cast iron

Depth (mm)

254

Made in

England

Heat output (ΔT50) Watts

3108

Heat Output (ΔT50) BTUs

10604

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1090_g6c_485
