Florence 6 Column 1200mm
Steel · by Castrads
From: £531.60
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install
- Heat pump compatible
- 10 year warranty
- Not suitable for steam
- Welded joins with powder coat finish
- Made in Italy
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 1302 |
| E | Height Without Legs (mm) | 1202 |
| - | Empty Leg Section Weight (kg) | 5.2 |
| - | Empty Mid Section Weight (kg) | 4.9 |
| B | Bottom Inlet To Floor (mm) | 134 |
| C | Max Section Depth (mm) | 217 |
| G | Mid Section Depth (mm) | 215 |
| D | Interaxis Distance (mm) | 1135 |
| F | Section Length (mm) | 45 |
| - | Output (ΔT50, W) | 211.2 |
| - | Output (ΔT30, W) | 104.9 |
| - | Internal Volume (L) | 3.33 |
| - | Exponent, n | 1.37095 |
| - | Factor, Km | 0.9897 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| SMC-F6C-1202-3 | 3 | 161 | 634 | 315 | 1 | £531.60 |
| SMC-F6C-1202-4 | 4 | 206 | 845 | 419 | 1 | £648.00 |
| SMC-F6C-1202-5 | 5 | 251 | 1056 | 524 | 1 | £764.40 |
| SMC-F6C-1202-6 | 6 | 296 | 1267 | 629 | 1 | £880.80 |
| SMC-F6C-1202-7 | 7 | 341 | 1478 | 734 | 1 | £997.20 |
| SMC-F6C-1202-8 | 8 | 386 | 1690 | 839 | 1 | £1,113.60 |
| SMC-F6C-1202-9 | 9 | 431 | 1901 | 944 | 1 | £1,230.00 |
| SMC-F6C-1202-10 | 10 | 476 | 2112 | 1048 | 1 | £1,346.40 |
| SMC-F6C-1202-11 | 11 | 521 | 2323 | 1153 | 1 | £1,462.80 |
| SMC-F6C-1202-12 | 12 | 566 | 2534 | 1258 | 1 | £1,579.20 |
| SMC-F6C-1202-13 | 13 | 611 | 2746 | 1363 | 1 | £1,695.60 |
| SMC-F6C-1202-14 | 14 | 656 | 2957 | 1468 | 1 | £1,812.00 |
| SMC-F6C-1202-15 | 15 | 701 | 3168 | 1573 | 1 | £1,928.40 |
| SMC-F6C-1202-16 | 16 | 746 | 3379 | 1678 | 1 | £2,044.80 |
| SMC-F6C-1202-17 | 17 | 791 | 3591 | 1782 | 1 | £2,161.20 |
| SMC-F6C-1202-18 | 18 | 836 | 3802 | 1887 | 1 | £2,277.60 |
| SMC-F6C-1202-19 | 19 | 881 | 4013 | 1992 | 1 | £2,394.00 |
| SMC-F6C-1202-20 | 20 | 926 | 4224 | 2097 | 1 | £2,510.40 |
| SMC-F6C-1202-21 | 21 | 971 | 4435 | 2202 | 1 | £2,626.80 |
| SMC-F6C-1202-22 | 22 | 1016 | 4647 | 2307 | 1 | £2,743.20 |
| SMC-F6C-1202-23 | 23 | 1061 | 4858 | 2412 | 1 | £2,859.60 |
| SMC-F6C-1202-24 | 24 | 1106 | 5069 | 2516 | 1 | £2,976.00 |
| SMC-F6C-1202-25 | 25 | 1151 | 5280 | 2621 | 1 | £3,092.40 |
| SMC-F6C-1202-26 | 26 | 1196 | 5491 | 2726 | 1 | £3,208.80 |
| SMC-F6C-1202-27 | 27 | 1241 | 5703 | 2831 | 1 | £3,325.20 |
| SMC-F6C-1202-28 | 28 | 1286 | 5914 | 2936 | 1 | £3,441.60 |
| SMC-F6C-1202-29 | 29 | 1331 | 6125 | 3041 | 1 | £3,558.00 |
| SMC-F6C-1202-30 | 30 | 1376 | 6336 | 3145 | 1 | £3,674.40 |
| SMC-F6C-1202-31 | 31 | 1421 | 6547 | 3250 | 1 | £3,790.80 |
| SMC-F6C-1202-32 | 32 | 1466 | 6759 | 3355 | 1 | £3,907.20 |
| SMC-F6C-1202-33 | 33 | 1511 | 6970 | 3460 | 1 | £4,023.60 |
| SMC-F6C-1202-34 | 34 | 1556 | 7181 | 3565 | 1 | £4,140.00 |
| SMC-F6C-1202-35 | 35 | 1601 | 7392 | 3670 | 1 | £4,256.40 |
| SMC-F6C-1202-36 | 36 | 1646 | 7603 | 3775 | 1 | £4,372.80 |
| SMC-F6C-1202-37 | 37 | 1691 | 7815 | 3879 | 1 | £4,489.20 |
| SMC-F6C-1202-38 | 38 | 1736 | 8026 | 3984 | 1 | £4,605.60 |
| SMC-F6C-1202-39 | 39 | 1781 | 8237 | 4089 | 1 | £4,722.00 |
| SMC-F6C-1202-40 | 40 | 1826 | 8448 | 4194 | 1 | £4,838.40 |
