Florence 2 Column 900mm
Steel · by Castrads
From: £286.80
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install
- Heat pump compatible
- 10 year warranty
- Not suitable for steam
- Welded joins with powder coat finish
- Made in Italy
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 1002 |
| E | Height Without Legs (mm) | 902 |
| - | Empty Leg Section Weight (kg) | 1.5 |
| - | Empty Mid Section Weight (kg) | 1.2 |
| B | Bottom Inlet To Floor (mm) | 134 |
| C | Max Section Depth (mm) | 67 |
| G | Mid Section Depth (mm) | 65 |
| D | Interaxis Distance (mm) | 835 |
| F | Section Length (mm) | 45 |
| - | Output (ΔT50, W) | 62.7 |
| - | Output (ΔT30, W) | 32.5 |
| - | Internal Volume (L) | 0.9 |
| - | Exponent, n | 1.2864 |
| - | Factor, Km | 0.4087 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| SMC-F2C-902-3 | 3 | 161 | 188 | 97 | 1 | £286.80 |
| SMC-F2C-902-4 | 4 | 206 | 251 | 130 | 1 | £321.60 |
| SMC-F2C-902-5 | 5 | 251 | 313 | 162 | 1 | £356.40 |
| SMC-F2C-902-6 | 6 | 296 | 376 | 195 | 1 | £391.20 |
| SMC-F2C-902-7 | 7 | 341 | 439 | 227 | 1 | £426.00 |
| SMC-F2C-902-8 | 8 | 386 | 501 | 260 | 1 | £460.80 |
| SMC-F2C-902-9 | 9 | 431 | 564 | 292 | 1 | £495.60 |
| SMC-F2C-902-10 | 10 | 476 | 627 | 325 | 1 | £530.40 |
| SMC-F2C-902-11 | 11 | 521 | 689 | 357 | 1 | £565.20 |
| SMC-F2C-902-12 | 12 | 566 | 752 | 390 | 1 | £600.00 |
| SMC-F2C-902-13 | 13 | 611 | 815 | 422 | 1 | £634.80 |
| SMC-F2C-902-14 | 14 | 656 | 877 | 455 | 1 | £669.60 |
| SMC-F2C-902-15 | 15 | 701 | 940 | 487 | 1 | £704.40 |
| SMC-F2C-902-16 | 16 | 746 | 1002 | 520 | 1 | £739.20 |
| SMC-F2C-902-17 | 17 | 791 | 1065 | 552 | 1 | £774.00 |
| SMC-F2C-902-18 | 18 | 836 | 1128 | 585 | 1 | £808.80 |
| SMC-F2C-902-19 | 19 | 881 | 1190 | 617 | 1 | £843.60 |
| SMC-F2C-902-20 | 20 | 926 | 1253 | 650 | 1 | £878.40 |
| SMC-F2C-902-21 | 21 | 971 | 1316 | 682 | 1 | £913.20 |
| SMC-F2C-902-22 | 22 | 1016 | 1378 | 714 | 1 | £948.00 |
| SMC-F2C-902-23 | 23 | 1061 | 1441 | 747 | 1 | £982.80 |
| SMC-F2C-902-24 | 24 | 1106 | 1504 | 779 | 1 | £1,017.60 |
| SMC-F2C-902-25 | 25 | 1151 | 1566 | 812 | 1 | £1,052.40 |
| SMC-F2C-902-26 | 26 | 1196 | 1629 | 844 | 1 | £1,087.20 |
| SMC-F2C-902-27 | 27 | 1241 | 1692 | 877 | 1 | £1,122.00 |
| SMC-F2C-902-28 | 28 | 1286 | 1754 | 909 | 1 | £1,156.80 |
| SMC-F2C-902-29 | 29 | 1331 | 1817 | 942 | 1 | £1,191.60 |
| SMC-F2C-902-30 | 30 | 1376 | 1880 | 974 | 1 | £1,226.40 |
| SMC-F2C-902-31 | 31 | 1421 | 1942 | 1007 | 1 | £1,261.20 |
| SMC-F2C-902-32 | 32 | 1466 | 2005 | 1039 | 1 | £1,296.00 |
| SMC-F2C-902-33 | 33 | 1511 | 2068 | 1072 | 1 | £1,330.80 |
| SMC-F2C-902-34 | 34 | 1556 | 2130 | 1104 | 1 | £1,365.60 |
| SMC-F2C-902-35 | 35 | 1601 | 2193 | 1137 | 1 | £1,400.40 |
| SMC-F2C-902-36 | 36 | 1646 | 2256 | 1169 | 1 | £1,435.20 |
| SMC-F2C-902-37 | 37 | 1691 | 2318 | 1202 | 1 | £1,470.00 |
| SMC-F2C-902-38 | 38 | 1736 | 2381 | 1234 | 1 | £1,504.80 |
| SMC-F2C-902-39 | 39 | 1781 | 2444 | 1267 | 1 | £1,539.60 |
| SMC-F2C-902-40 | 40 | 1826 | 2506 | 1299 | 1 | £1,574.40 |
