• Mercury 6 column 960mm Castrads radiator in Matt Black finish

Mercury 6 Column 38in

From: $1,022.00

Technical specs at 3 sections long:

Length
Heat output (Hydronic)
Height
Heat output (Steam)
Depth
Delivered in
SKU: CI-M6C-960

Model Specifications

Label Attribute Value
A Height With Legs 37.8 in
B Bottom Inlet To Floor 3.9 in
C Max Section Depth 8.5 in
D Interaxis Distance 32.4 in
E Height Without Legs 35.4 in
F Section Length 2.3 in
G Mid Section Depth 8.5 in
- Internal Volume 0.40 gal
- Empty Leg Section Weight 27.78 lb
- Empty Mid Section Weight 26.23 lb
- EDR Per Section 4.62 ft²
- Hydronic Output (170ºF) 692 BTUs
- Steam Output (215ºF) 1108 BTUs
Mercury 6 Column 960mm - Single Section Technical Drawing - SVG

Sizes Available

SKU N
Secs
Length
(L, mm)
Output
(Hydronic, 170ºF)
Output
(Steam, 215ºF)
EDR Delivery
pieces
Price
from
CI-M6C-960-3 3 8.0 in 2076 BTUs 3324 BTUs 13.9 ft² 3 $1,022.00
CI-M6C-960-4 4 10.4 in 2768 BTUs 4432 BTUs 18.5 ft² 1 $1,091.00
CI-M6C-960-5 5 12.6 in 3460 BTUs 5540 BTUs 23.1 ft² 3 $1,320.00
CI-M6C-960-6 6 14.9 in 4152 BTUs 6648 BTUs 27.7 ft² 3 $1,469.00
CI-M6C-960-7 7 17.2 in 4844 BTUs 7756 BTUs 32.3 ft² 4 $1,618.00
CI-M6C-960-8 8 19.5 in 5536 BTUs 8864 BTUs 37.0 ft² 1 $1,687.00
CI-M6C-960-9 9 21.8 in 6228 BTUs 9972 BTUs 41.6 ft² 5 $1,916.00
CI-M6C-960-10 10 24.1 in 6920 BTUs 11080 BTUs 46.2 ft² 4 $2,065.00
CI-M6C-960-11 11 26.4 in 7612 BTUs 12188 BTUs 50.8 ft² 4 $2,214.00
CI-M6C-960-12 12 28.7 in 8304 BTUs 13296 BTUs 55.4 ft² 4 $2,363.00
CI-M6C-960-13 13 31.0 in 8996 BTUs 14404 BTUs 60.1 ft² 2 $2,512.00
CI-M6C-960-14 14 33.3 in 9688 BTUs 15512 BTUs 64.7 ft² 2 $2,661.00
CI-M6C-960-15 15 35.6 in 10380 BTUs 16620 BTUs 69.3 ft² 4 $2,810.00
CI-M6C-960-16 16 37.9 in 11072 BTUs 17728 BTUs 73.9 ft² 3 $2,959.00
CI-M6C-960-17 17 40.2 in 11764 BTUs 18836 BTUs 78.5 ft² 5 $3,108.00
CI-M6C-960-18 18 42.5 in 12456 BTUs 19944 BTUs 83.2 ft² 5 $3,257.00
CI-M6C-960-19 19 44.8 in 13148 BTUs 21052 BTUs 87.8 ft² 5 $3,406.00
CI-M6C-960-20 20 47.1 in 13840 BTUs 22160 BTUs 92.4 ft² 1 $3,475.00
CI-M6C-960-21 21 49.4 in 14532 BTUs 23268 BTUs 97.0 ft² 4 $3,704.00
CI-M6C-960-22 22 51.7 in 15224 BTUs 24376 BTUs 101.6 ft² 3 $3,853.00
CI-M6C-960-23 23 53.9 in 15916 BTUs 25484 BTUs 106.3 ft² 4 $4,002.00
CI-M6C-960-24 24 56.3 in 16608 BTUs 26592 BTUs 110.9 ft² 4 $4,151.00
CI-M6C-960-25 25 58.5 in 17300 BTUs 27700 BTUs 115.5 ft² 2 $4,300.00
CI-M6C-960-26 26 60.8 in 17992 BTUs 28808 BTUs 120.1 ft² 3 $4,449.00
CI-M6C-960-27 27 63.1 in 18684 BTUs 29916 BTUs 124.7 ft² 3 $4,598.00
CI-M6C-960-28 28 65.4 in 19376 BTUs 31024 BTUs 129.4 ft² 3 $4,747.00
CI-M6C-960-29 29 67.7 in 20068 BTUs 32132 BTUs 134.0 ft² 4 $4,896.00
CI-M6C-960-30 30 70.0 in 20760 BTUs 33240 BTUs 138.6 ft² 2 $5,045.00
CI-M6C-960-31 31 72.3 in 21452 BTUs 34348 BTUs 143.2 ft² 2 $5,194.00
CI-M6C-960-32 32 74.6 in 22144 BTUs 35456 BTUs 147.8 ft² 1 $5,263.00
CI-M6C-960-33 33 76.9 in 22836 BTUs 36564 BTUs 152.5 ft² 2 $5,492.00
CI-M6C-960-34 34 79.2 in 23528 BTUs 37672 BTUs 157.1 ft² 2 $5,641.00
CI-M6C-960-35 35 81.5 in 24220 BTUs 38780 BTUs 161.7 ft² 1 $5,710.00
CI-M6C-960-36 36 83.8 in 24912 BTUs 39888 BTUs 166.3 ft² 1 $5,859.00
CI-M6C-960-37 37 86.1 in 25604 BTUs 40996 BTUs 170.9 ft² 4 $6,088.00
CI-M6C-960-38 38 88.4 in 26296 BTUs 42104 BTUs 175.6 ft² 2 $6,237.00
CI-M6C-960-39 39 90.7 in 26988 BTUs 43212 BTUs 180.2 ft² 2 $6,386.00
CI-M6C-960-40 40 93.0 in 27680 BTUs 44320 BTUs 184.8 ft² 2 $6,535.00
Mercury 6 Column 960mm - 10 Section Battery Technical Drawing - SVG
