Mercury 4 Column 14in
Cast Iron · by Castrads
From: $289.00
Technical specs at 3 sections long:
| Length | Heat output (Hydronic) | ||
| Height | Heat output (Steam) | ||
| Depth | Delivered in |
A cast iron column radiator, exclusive to Castrads, with a refined, symmetrical profile inspired by original designs from the 1920s.
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 18 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs | 14.17 in |
| E | Height Without Legs | 11.73 in |
| - | Empty Leg Section Weight | 8.16 lb |
| - | Empty Mid Section Weight | 6.39 lb |
| B | Bottom Inlet To Floor | 3.94 in |
| C | Max Section Depth | 5.51 in |
| G | Mid Section Depth | 5.51 in |
| D | Interaxis Distance | 8.78 in |
| F | Section Length | 2.30 in |
| - | Internal Volume | 0.03 gal |
| - | EDR Per Section | 1.17 ft² |
| - | Hydronic Output (170ºF) | 176 BTUs |
| - | Steam Output (215ºF) | 278 BTUs |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (Hydronic, 170ºF) |
Output (Steam, 215ºF) |
EDR | Delivery pieces |
Price from |
|---|---|---|---|---|---|---|---|
| CI-M4C-360-3 | 3 | 8.03 in | 529 BTUs | 834 BTUs | 3.5 ft² | 1 | $289.00 |
| CI-M4C-360-4 | 4 | 10.35 in | 706 BTUs | 1112 BTUs | 4.7 ft² | 1 | $328.00 |
| CI-M4C-360-5 | 5 | 12.64 in | 882 BTUs | 1390 BTUs | 5.9 ft² | 1 | $367.00 |
| CI-M4C-360-6 | 6 | 14.92 in | 1058 BTUs | 1668 BTUs | 7.0 ft² | 1 | $406.00 |
| CI-M4C-360-7 | 7 | 17.24 in | 1235 BTUs | 1946 BTUs | 8.2 ft² | 1 | $445.00 |
| CI-M4C-360-8 | 8 | 19.53 in | 1411 BTUs | 2224 BTUs | 9.4 ft² | 1 | $484.00 |
| CI-M4C-360-9 | 9 | 21.81 in | 1588 BTUs | 2502 BTUs | 10.5 ft² | 1 | $523.00 |
| CI-M4C-360-10 | 10 | 24.13 in | 1764 BTUs | 2780 BTUs | 11.7 ft² | 1 | $562.00 |
| CI-M4C-360-11 | 11 | 26.42 in | 1940 BTUs | 3058 BTUs | 12.9 ft² | 1 | $601.00 |
| CI-M4C-360-12 | 12 | 28.70 in | 2117 BTUs | 3336 BTUs | 14.0 ft² | 1 | $640.00 |
| CI-M4C-360-13 | 13 | 30.98 in | 2293 BTUs | 3615 BTUs | 15.2 ft² | 1 | $679.00 |
| CI-M4C-360-14 | 14 | 33.31 in | 2470 BTUs | 3893 BTUs | 16.4 ft² | 1 | $718.00 |
| CI-M4C-360-15 | 15 | 35.59 in | 2646 BTUs | 4171 BTUs | 17.6 ft² | 1 | $757.00 |
| CI-M4C-360-16 | 16 | 37.87 in | 2822 BTUs | 4449 BTUs | 18.7 ft² | 1 | $796.00 |
| CI-M4C-360-17 | 17 | 40.20 in | 2999 BTUs | 4727 BTUs | 19.9 ft² | 1 | $835.00 |
| CI-M4C-360-18 | 18 | 42.48 in | 3175 BTUs | 5005 BTUs | 21.1 ft² | 1 | $874.00 |
| CI-M4C-360-19 | 19 | 44.76 in | 3352 BTUs | 5283 BTUs | 22.2 ft² | 2 | $986.00 |
| CI-M4C-360-20 | 20 | 47.09 in | 3528 BTUs | 5561 BTUs | 23.4 ft² | 2 | $1,025.00 |
| CI-M4C-360-21 | 21 | 49.37 in | 3704 BTUs | 5839 BTUs | 24.6 ft² | 2 | $1,064.00 |
| CI-M4C-360-22 | 22 | 51.65 in | 3881 BTUs | 6117 BTUs | 25.7 ft² | 2 | $1,103.00 |
| CI-M4C-360-23 | 23 | 53.94 in | 4057 BTUs | 6395 BTUs | 26.9 ft² | 2 | $1,142.00 |
| CI-M4C-360-24 | 24 | 56.26 in | 4234 BTUs | 6673 BTUs | 28.1 ft² | 2 | $1,181.00 |
| CI-M4C-360-25 | 25 | 58.54 in | 4410 BTUs | 6951 BTUs | 29.3 ft² | 2 | $1,220.00 |
| CI-M4C-360-26 | 26 | 60.83 in | 4586 BTUs | 7229 BTUs | 30.4 ft² | 2 | $1,259.00 |
| CI-M4C-360-27 | 27 | 63.15 in | 4763 BTUs | 7507 BTUs | 31.6 ft² | 2 | $1,298.00 |
| CI-M4C-360-28 | 28 | 65.43 in | 4939 BTUs | 7785 BTUs | 32.8 ft² | 2 | $1,337.00 |
| CI-M4C-360-29 | 29 | 67.72 in | 5116 BTUs | 8063 BTUs | 33.9 ft² | 2 | $1,376.00 |
| CI-M4C-360-30 | 30 | 70.04 in | 5292 BTUs | 8341 BTUs | 35.1 ft² | 2 | $1,415.00 |
| CI-M4C-360-31 | 31 | 72.32 in | 5468 BTUs | 8619 BTUs | 36.3 ft² | 2 | $1,454.00 |
| CI-M4C-360-32 | 32 | 74.61 in | 5645 BTUs | 8897 BTUs | 37.4 ft² | 2 | $1,493.00 |
| CI-M4C-360-33 | 33 | 76.89 in | 5821 BTUs | 9175 BTUs | 38.6 ft² | 3 | $1,532.00 |
| CI-M4C-360-34 | 34 | 79.21 in | 5998 BTUs | 9453 BTUs | 39.8 ft² | 3 | $1,571.00 |
| CI-M4C-360-35 | 35 | 81.50 in | 6174 BTUs | 9731 BTUs | 41.0 ft² | 3 | $1,610.00 |
| CI-M4C-360-36 | 36 | 83.78 in | 6350 BTUs | 10009 BTUs | 42.1 ft² | 3 | $1,649.00 |
| CI-M4C-360-37 | 37 | 86.10 in | 6527 BTUs | 10287 BTUs | 43.3 ft² | 3 | $1,688.00 |
| CI-M4C-360-38 | 38 | 88.39 in | 6703 BTUs | 10566 BTUs | 44.5 ft² | 3 | $1,727.00 |
| CI-M4C-360-39 | 39 | 90.67 in | 6880 BTUs | 10844 BTUs | 45.6 ft² | 3 | $1,766.00 |
| CI-M4C-360-40 | 40 | 92.99 in | 7056 BTUs | 11122 BTUs | 46.8 ft² | 3 | $1,805.00 |
