Rococo I 950mm
From: £441.60
Available on backorder
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
An ornate cast iron radiator, faithfully reproduced from an American Radiator Company original.
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 12 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 5-6 weeks lead time
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 950 |
| - | Empty Leg Section Weight (kg) | 9.9 |
| - | Empty Mid Section Weight (kg) | 9.1 |
| B | Bottom Inlet To Floor (mm) | 110 |
| C | Max Section Depth (mm) | 140 |
| - | Output (ΔT50, W) | 104.3 |
| - | Output (ΔT30, W) | 54 |
| D | Interaxis Distance (mm) | 790 |
| E | Height Without Legs (mm) | 895 |
| F | Section Length (mm) | 76 |
| G | Mid Section Depth (mm) | 114 |
| - | Internal Volume (L) | 1.3 |
| - | Factor, Km | 0.6716 |
| - | Exponent, n | 1.2896 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| CI-RC1-950-3 | 3 | 258 | 312 | 162 | 1 | £441.60 |
| CI-RC1-950-4 | 4 | 334 | 417 | 216 | 1 | £532.80 |
| CI-RC1-950-5 | 5 | 410 | 521 | 270 | 1 | £624.00 |
| CI-RC1-950-6 | 6 | 486 | 625 | 324 | 1 | £715.20 |
| CI-RC1-950-7 | 7 | 562 | 730 | 378 | 1 | £806.40 |
| CI-RC1-950-8 | 8 | 638 | 834 | 432 | 1 | £897.60 |
| CI-RC1-950-9 | 9 | 714 | 938 | 486 | 1 | £988.80 |
| CI-RC1-950-10 | 10 | 790 | 1043 | 540 | 1 | £1,080.00 |
| CI-RC1-950-11 | 11 | 866 | 1147 | 594 | 1 | £1,171.20 |
| CI-RC1-950-12 | 12 | 942 | 1251 | 648 | 1 | £1,262.40 |
| CI-RC1-950-13 | 13 | 1018 | 1355 | 702 | 2 | £1,441.20 |
| CI-RC1-950-14 | 14 | 1094 | 1460 | 756 | 2 | £1,532.40 |
| CI-RC1-950-15 | 15 | 1170 | 1564 | 810 | 2 | £1,623.60 |
| CI-RC1-950-16 | 16 | 1246 | 1668 | 864 | 2 | £1,714.80 |
| CI-RC1-950-17 | 17 | 1322 | 1773 | 918 | 2 | £1,806.00 |
| CI-RC1-950-18 | 18 | 1398 | 1877 | 972 | 2 | £1,897.20 |
| CI-RC1-950-19 | 19 | 1474 | 1981 | 1026 | 2 | £1,988.40 |
| CI-RC1-950-20 | 20 | 1550 | 2086 | 1080 | 3 | £2,079.60 |
| CI-RC1-950-21 | 21 | 1626 | 2190 | 1134 | 3 | £2,170.80 |
| CI-RC1-950-22 | 22 | 1702 | 2294 | 1188 | 3 | £2,262.00 |
| CI-RC1-950-23 | 23 | 1778 | 2398 | 1242 | 3 | £2,353.20 |
| CI-RC1-950-24 | 24 | 1854 | 2503 | 1296 | 3 | £2,444.40 |
| CI-RC1-950-25 | 25 | 1930 | 2607 | 1350 | 3 | £2,535.60 |
| CI-RC1-950-26 | 26 | 2006 | 2711 | 1404 | 3 | £2,626.80 |
| CI-RC1-950-27 | 27 | 2082 | 2816 | 1458 | 3 | £2,718.00 |
| CI-RC1-950-28 | 28 | 2158 | 2920 | 1512 | 3 | £2,809.20 |
| CI-RC1-950-29 | 29 | 2234 | 3024 | 1566 | 3 | £2,900.40 |
| CI-RC1-950-30 | 30 | 2310 | 3129 | 1620 | 3 | £2,991.60 |
| CI-RC1-950-31 | 31 | 2386 | 3233 | 1674 | 3 | £3,082.80 |
| CI-RC1-950-32 | 32 | 2462 | 3337 | 1728 | 4 | £3,174.00 |
| CI-RC1-950-33 | 33 | 2538 | 3441 | 1782 | 4 | £3,265.20 |
| CI-RC1-950-34 | 34 | 2614 | 3546 | 1836 | 4 | £3,356.40 |
| CI-RC1-950-35 | 35 | 2690 | 3650 | 1890 | 4 | £3,447.60 |
| CI-RC1-950-36 | 36 | 2766 | 3754 | 1944 | 4 | £3,538.80 |
| CI-RC1-950-37 | 37 | 2842 | 3859 | 1998 | 4 | £3,630.00 |
| CI-RC1-950-38 | 38 | 2918 | 3963 | 2052 | 4 | £3,721.20 |
| CI-RC1-950-39 | 39 | 2994 | 4067 | 2106 | 4 | £3,812.40 |
| CI-RC1-950-40 | 40 | 3070 | 4172 | 2160 | 5 | £3,903.60 |
