Florence 2 Column 200mm
Steel · by Castrads
From: £272.40
Technical specs at 3 sections long:
| Length | Heat output (∆T50) | ||
| Height | Pipe centres | ||
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install
- Heat pump compatible
- 10 year warranty
- Not suitable for steam
- Welded joins with powder coat finish
- Made in Italy
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs (mm) | 294 |
| E | Height Without Legs (mm) | 194 |
| - | Empty Leg Section Weight (kg) | 0.6 |
| - | Empty Mid Section Weight (kg) | 0.3 |
| B | Bottom Inlet To Floor (mm) | 134 |
| C | Max Section Depth (mm) | 67 |
| G | Mid Section Depth (mm) | 65 |
| D | Interaxis Distance (mm) | 1935 |
| F | Section Length (mm) | 45 |
| - | Output (ΔT50, W) | 14.9 |
| - | Output (ΔT30, W) | 7.9 |
| - | Internal Volume (L) | 0.3 |
| - | Exponent, n | 1.25221 |
| - | Factor, Km | 0.1112 |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (∆T50, Watts) |
Output (∆T30, Watts) |
Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| SMC-F2C-194-3 | 3 | 161 | 45 | 24 | 1 | £272.40 |
| SMC-F2C-194-4 | 4 | 206 | 60 | 31 | 1 | £302.40 |
| SMC-F2C-194-5 | 5 | 251 | 75 | 39 | 1 | £332.40 |
| SMC-F2C-194-6 | 6 | 296 | 89 | 47 | 1 | £362.40 |
| SMC-F2C-194-7 | 7 | 341 | 104 | 55 | 1 | £392.40 |
| SMC-F2C-194-8 | 8 | 386 | 119 | 63 | 1 | £422.40 |
| SMC-F2C-194-9 | 9 | 431 | 134 | 71 | 1 | £452.40 |
| SMC-F2C-194-10 | 10 | 476 | 149 | 79 | 1 | £482.40 |
| SMC-F2C-194-11 | 11 | 521 | 164 | 87 | 1 | £512.40 |
| SMC-F2C-194-12 | 12 | 566 | 179 | 94 | 1 | £542.40 |
| SMC-F2C-194-13 | 13 | 611 | 194 | 102 | 1 | £572.40 |
| SMC-F2C-194-14 | 14 | 656 | 209 | 110 | 1 | £602.40 |
| SMC-F2C-194-15 | 15 | 701 | 224 | 118 | 1 | £632.40 |
| SMC-F2C-194-16 | 16 | 746 | 239 | 126 | 1 | £662.40 |
| SMC-F2C-194-17 | 17 | 791 | 254 | 134 | 1 | £692.40 |
| SMC-F2C-194-18 | 18 | 836 | 268 | 142 | 1 | £722.40 |
| SMC-F2C-194-19 | 19 | 881 | 283 | 149 | 1 | £752.40 |
| SMC-F2C-194-20 | 20 | 926 | 298 | 157 | 1 | £782.40 |
| SMC-F2C-194-21 | 21 | 971 | 313 | 165 | 1 | £812.40 |
| SMC-F2C-194-22 | 22 | 1016 | 328 | 173 | 1 | £842.40 |
| SMC-F2C-194-23 | 23 | 1061 | 343 | 181 | 1 | £872.40 |
| SMC-F2C-194-24 | 24 | 1106 | 358 | 189 | 1 | £902.40 |
| SMC-F2C-194-25 | 25 | 1151 | 373 | 197 | 1 | £932.40 |
| SMC-F2C-194-26 | 26 | 1196 | 388 | 205 | 1 | £962.40 |
| SMC-F2C-194-27 | 27 | 1241 | 403 | 212 | 1 | £992.40 |
| SMC-F2C-194-28 | 28 | 1286 | 418 | 220 | 1 | £1,022.40 |
| SMC-F2C-194-29 | 29 | 1331 | 432 | 228 | 1 | £1,052.40 |
| SMC-F2C-194-30 | 30 | 1376 | 447 | 236 | 1 | £1,082.40 |
| SMC-F2C-194-31 | 31 | 1421 | 462 | 244 | 1 | £1,112.40 |
| SMC-F2C-194-32 | 32 | 1466 | 477 | 252 | 1 | £1,142.40 |
| SMC-F2C-194-33 | 33 | 1511 | 492 | 260 | 1 | £1,172.40 |
| SMC-F2C-194-34 | 34 | 1556 | 507 | 267 | 1 | £1,202.40 |
| SMC-F2C-194-35 | 35 | 1601 | 522 | 275 | 1 | £1,232.40 |
| SMC-F2C-194-36 | 36 | 1646 | 537 | 283 | 1 | £1,262.40 |
| SMC-F2C-194-37 | 37 | 1691 | 552 | 291 | 1 | £1,292.40 |
| SMC-F2C-194-38 | 38 | 1736 | 567 | 299 | 1 | £1,322.40 |
| SMC-F2C-194-39 | 39 | 1781 | 582 | 307 | 1 | £1,352.40 |
| SMC-F2C-194-40 | 40 | 1826 | 597 | 315 | 1 | £1,382.40 |
