Emmeline II 18in
From: $770.00
Technical specs at 3 sections long:
| Length | Heat output (Hydronic) | ||
| Height | Heat output (Steam) | ||
| Depth | Delivered in |
A traditional cast iron radiator, exclusive to Castrads, with a smooth surface and curved top inspired by early 20th-century school radiators.
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install up to 16 sections
- Partial home assembly required for larger radiators
- Heat pump compatible
- 25 year warranty
- Made in England
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs | 18.5 in |
| B | Bottom Inlet To Floor | 3.9 in |
| C | Max Section Depth | 6.7 in |
| D | Interaxis Distance | 12.7 in |
| E | Height Without Legs | 16.3 in |
| F | Section Length | 2.6 in |
| G | Mid Section Depth | 5.9 in |
| - | Internal Volume | 0.28 gal |
| - | Empty Leg Section Weight | 11.68 lb |
| - | Empty Mid Section Weight | 9.48 lb |
| - | EDR Per Section | 1.63 ft² |
| - | Hydronic Output (170ºF) | 244 BTUs |
| - | Steam Output (215ºF) | 388 BTUs |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (Hydronic, 170ºF) |
Output (Steam, 215ºF) |
EDR | Delivery pieces |
Price from |
|---|---|---|---|---|---|---|---|
| CI-EML2-470-3 | 3 | 9.0 in | 731 BTUs | 1165 BTUs | 4.9 ft² | 1 | $770.00 |
| CI-EML2-470-4 | 4 | 11.7 in | 975 BTUs | 1553 BTUs | 6.5 ft² | 1 | $855.00 |
| CI-EML2-470-5 | 5 | 14.3 in | 1218 BTUs | 1941 BTUs | 8.2 ft² | 1 | $940.00 |
| CI-EML2-470-6 | 6 | 16.9 in | 1462 BTUs | 2329 BTUs | 9.8 ft² | 1 | $1,025.00 |
| CI-EML2-470-7 | 7 | 19.5 in | 1706 BTUs | 2718 BTUs | 11.4 ft² | 1 | $1,110.00 |
| CI-EML2-470-8 | 8 | 22.1 in | 1950 BTUs | 3106 BTUs | 13.0 ft² | 1 | $1,195.00 |
| CI-EML2-470-9 | 9 | 24.7 in | 2193 BTUs | 3494 BTUs | 14.7 ft² | 1 | $1,280.00 |
| CI-EML2-470-10 | 10 | 27.4 in | 2437 BTUs | 3882 BTUs | 16.3 ft² | 1 | $1,365.00 |
| CI-EML2-470-11 | 11 | 30.0 in | 2681 BTUs | 4270 BTUs | 17.9 ft² | 1 | $1,450.00 |
| CI-EML2-470-12 | 12 | 32.6 in | 2924 BTUs | 4659 BTUs | 19.6 ft² | 1 | $1,535.00 |
| CI-EML2-470-13 | 13 | 35.2 in | 3168 BTUs | 5047 BTUs | 21.2 ft² | 1 | $1,620.00 |
| CI-EML2-470-14 | 14 | 37.8 in | 3412 BTUs | 5435 BTUs | 22.8 ft² | 1 | $1,705.00 |
| CI-EML2-470-15 | 15 | 40.4 in | 3655 BTUs | 5823 BTUs | 24.5 ft² | 1 | $1,790.00 |
| CI-EML2-470-16 | 16 | 43.1 in | 3899 BTUs | 6211 BTUs | 26.1 ft² | 1 | $1,875.00 |
| CI-EML2-470-17 | 17 | 45.7 in | 4143 BTUs | 6600 BTUs | 27.7 ft² | 2 | $2,043.00 |
| CI-EML2-470-18 | 18 | 48.3 in | 4386 BTUs | 6988 BTUs | 29.3 ft² | 2 | $2,128.00 |
| CI-EML2-470-19 | 19 | 50.9 in | 4630 BTUs | 7376 BTUs | 31.0 ft² | 2 | $2,213.00 |
| CI-EML2-470-20 | 20 | 53.5 in | 4874 BTUs | 7764 BTUs | 32.6 ft² | 2 | $2,298.00 |
| CI-EML2-470-21 | 21 | 56.1 in | 5117 BTUs | 8153 BTUs | 34.2 ft² | 2 | $2,383.00 |
| CI-EML2-470-22 | 22 | 58.8 in | 5361 BTUs | 8541 BTUs | 35.9 ft² | 2 | $2,468.00 |
| CI-EML2-470-23 | 23 | 61.4 in | 5605 BTUs | 8929 BTUs | 37.5 ft² | 2 | $2,553.00 |
| CI-EML2-470-24 | 24 | 64.0 in | 5849 BTUs | 9317 BTUs | 39.1 ft² | 2 | $2,638.00 |
| CI-EML2-470-25 | 25 | 66.6 in | 6092 BTUs | 9705 BTUs | 40.8 ft² | 2 | $2,723.00 |
| CI-EML2-470-26 | 26 | 69.3 in | 6336 BTUs | 10094 BTUs | 42.4 ft² | 3 | $2,808.00 |
| CI-EML2-470-27 | 27 | 71.9 in | 6580 BTUs | 10482 BTUs | 44.0 ft² | 3 | $2,893.00 |
| CI-EML2-470-28 | 28 | 74.5 in | 6823 BTUs | 10870 BTUs | 45.6 ft² | 3 | $2,978.00 |
| CI-EML2-470-29 | 29 | 77.1 in | 7067 BTUs | 11258 BTUs | 47.3 ft² | 3 | $3,063.00 |
| CI-EML2-470-30 | 30 | 79.7 in | 7311 BTUs | 11646 BTUs | 48.9 ft² | 3 | $3,148.00 |
| CI-EML2-470-31 | 31 | 82.3 in | 7554 BTUs | 12035 BTUs | 50.5 ft² | 3 | $3,233.00 |
| CI-EML2-470-32 | 32 | 85.0 in | 7798 BTUs | 12423 BTUs | 52.2 ft² | 3 | $3,318.00 |
| CI-EML2-470-33 | 33 | 87.6 in | 8042 BTUs | 12811 BTUs | 53.8 ft² | 3 | $3,403.00 |
| CI-EML2-470-34 | 34 | 90.2 in | 8285 BTUs | 13199 BTUs | 55.4 ft² | 3 | $3,488.00 |
| CI-EML2-470-35 | 35 | 92.8 in | 8529 BTUs | 13588 BTUs | 57.1 ft² | 3 | $3,573.00 |
| CI-EML2-470-36 | 36 | 95.4 in | 8773 BTUs | 13976 BTUs | 58.7 ft² | 3 | $3,658.00 |
| CI-EML2-470-37 | 37 | 98.0 in | 9017 BTUs | 14364 BTUs | 60.3 ft² | 3 | $3,743.00 |
| CI-EML2-470-38 | 38 | 100.7 in | 9260 BTUs | 14752 BTUs | 61.9 ft² | 3 | $3,828.00 |
| CI-EML2-470-39 | 39 | 103.3 in | 9504 BTUs | 15140 BTUs | 63.6 ft² | 3 | $3,913.00 |
| CI-EML2-470-40 | 40 | 105.9 in | 9748 BTUs | 15529 BTUs | 65.2 ft² | 3 | $3,998.00 |
