From: $966.40
(H) | Height | 18.1in |
(D) | Depth | 5.5in |
(L) | Length | 14.8in |
(PC) | Pipe centers (½" hydronic only) | 18.3in* |
(TS) | Total space required | 21.8in |
* Do not lay pipes to this size as measurements may vary. Request actual measurements when placing your order.
Heat emission (Hydronic / 170°F) | 1386 BTUs |
Heat emission (Steam / 215°F) | 2218 BTUs |
EDR | 9.24 sq. ft. |
Empty weight | 51.0 lbs |
Delivery | 1 piece |
Weight | 51.0 lbs |
---|---|
Dimensions | 14.8 × 5.5 × 18.1 in |
Number of sections | 6 |
Hydronic output (170°F) | 1386 |
Certification | EN442 |
Steam output (215°F) | 2218 |
Construction material | Cast iron |
EDR (sq. ft.) | 9.24 |
Made in | England |
Maximum operating pressure | 30 psi (steam) / 116 psi (hydronic) |
Bleed valve (hydronic) / Vacuum breaker (steam) included | Brass or Nickel |
Connections | NPT, various sizes available |
