From: $1,785.40
(H) | Height | 18.1in |
(D) | Depth | 5.5in |
(L) | Length | 37.8in |
(PC) | Pipe centers (½" hydronic only) | 41.3in* |
(TS) | Total space required | 44.8in |
* Do not lay pipes to this size as measurements may vary. Request actual measurements when placing your order.
Heat emission (Hydronic / 170°F) | 3696 BTUs |
Heat emission (Steam / 215°F) | 5914 BTUs |
EDR | 24.64 sq. ft. |
Empty weight | 131.0 lbs |
Delivery | 1 piece |
Weight | 131.0 lbs |
---|---|
Dimensions | 37.8 × 5.5 × 18.1 in |
Number of sections | 16 |
Hydronic output (170°F) | 3696 |
Certification | EN442 |
Steam output (215°F) | 5914 |
Construction material | Cast iron |
EDR (sq. ft.) | 24.64 |
Made in | England |
Maximum operating pressure | 30 psi (steam) / 116 psi (hydronic) |
Bleed valve (hydronic) / Vacuum breaker (steam) included | Brass or Nickel |
Connections | NPT, various sizes available |
