Vulcan III 690mm, 17 sections

From: £859.37

  • 684mm tall, 1053mm long, 90mm deep.
  • Heat output (ΔT50): 1437 Watts
  • Heat output (ΔT50): 4901 BTUs
  • Weight: 83 kg
  • Guarantee: 10 years
  • Delivered in: 5 weeks (Signature range) / 6 weeks (Bare Metal)
  • Delivered ready for installation

Configure Radiator

Vulcan III 690mm, 17 sections

Description
Additional information
Radiator drawing
(H) Height 684mm
(D) Depth 90mm
(L) Length 1053mm
(PC) Pipe centres 1143mm
(TS) Total space required 1233mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 1437 Watts
Empty weight 83kg
Internal volume 13.94 L
Delivery 1 piece
Maximum operating pressure 0
Weight 83 kg
Dimensions 1053 × 90 × 684 mm
Number of sections

17

Certification

EN442

Construction material

Cast iron

Made in

England

Length (mm)

1053

Height (mm)

684

Depth (mm)

90

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Heat output (ΔT50) Watts

1437

Heat output (ΔT50) BTUs

4901

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Internal volume

13.94

Pipe centres Open document
