From: £662.14
| (H) | Height | 560mm |
| (D) | Depth | 140mm |
| (L) | Length | 715mm |
| (PC) | Pipe centres | 805mm |
| (TS) | Total space required | 895mm |
| Open pipe centre measurements document for more information. | ||
| Heat output (ΔT50) | 536 Watts |
| Empty weight | 54kg |
| Internal volume | 7.2 L |
| Delivery | 1 piece |
| Maximum operating pressure | 8 bar |
| Weight | 54 kg |
|---|---|
| Dimensions | 715 × 140 × 560 mm |
| Number of sections | 9 |
| Internal volume | 7.2 |
| Length (mm) | 715 |
| Certification | EN442 |
| Height (mm) | 560 |
| Construction material | Cast iron |
| Depth (mm) | 140 |
| Made in | England |
| Heat output (ΔT50) Watts | 536 |
| Heat Output (ΔT50) BTUs | 1827 |
| Maximum operating temperature | 95°C for hot water systems |
| Maximum operating pressure | 8 bar |
| Bleed valve included | Brass or Nickel |
| Connections | ½" BSP as standard |
| Pipe centres | Open document |
|---|
| Declaration of Performance | dop-202009-1129_rc1_560 |
