Rococo I 560mm, 6 sections | Castrads
  • £0.00

Rococo I 560mm, 6 sections

From: £491.42

  • 560mm tall, 487mm long, 140mm deep.
  • Heat output (ΔT50): 357 Watts
  • Heat output (ΔT50): 1218 BTUs
  • Weight: 33 kg
  • Guarantee: 10 years
  • Delivered in: 7-8 weeks
  • Delivered ready for installation

Configure Radiator

Rococo I 560mm, 6 sections

Description
Additional information
Product files
Radiator drawing
(H) Height 560mm
(D) Depth 140mm
(L) Length 487mm
(PC) Pipe centres 577mm
(TS) Total space required 667mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 357 Watts
Empty weight 37kg
Internal volume 4.8 L
Delivery 1 piece
Maximum operating pressure 8 bar
Weight 37 kg
Dimensions 487 × 140 × 560 mm
Number of sections

6

Internal volume

4.8

Length (mm)

487

Certification

EN442

Height (mm)

560

Construction material

Cast iron

Depth (mm)

140

Made in

England

Heat output (ΔT50) Watts

357

Heat Output (ΔT50) BTUs

1218

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1129_rc1_560
