Grace 6 Column 960mm, 13 sections

From: £1,457.05

  • 960mm tall, 813mm long, 250mm deep.
  • Heat output (ΔT50): 2272 Watts
  • Heat output (ΔT50): 7753 BTUs
  • Weight: 146 kg
  • Guarantee: 10 years
  • Delivered in: 6 weeks
  • Delivered in 2 pieces for partial home assembly. You will need to hire an Assembly Toolkit with purchase of this radiator.

Configure Radiator

Grace 6 Column 960mm, 13 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 960mm
(D) Depth 250mm
(L) Length 813mm
(PC) Pipe centres 903mm
(TS) Total space required 993mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 2272 Watts
Empty weight 146kg
Internal volume 0 L
Delivery 1 piece
Maximum operating pressure 0
Weight 146 kg
Dimensions 813 × 250 × 960 mm
Number of sections

13

Internal volume

20.8

Length (mm)

813

Certification

EN442

Height (mm)

960

Construction material

Cast iron

Depth (mm)

250

Made in

England

Heat output (ΔT50) Watts

2272

Heat output (ΔT50) BTUs

7753

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1093_g6c_960
