Grace 6 Column 485mm, 7 sections | Castrads
  • £0.00

Grace 6 Column 485mm, 7 sections

From: £499.27

  • 485mm tall, 451mm long, 254mm deep.
  • Heat output (ΔT50): 622 Watts
  • Heat output (ΔT50): 2121 BTUs
  • Weight: 47 kg
  • Guarantee: 10 years
  • Delivered in: 7-8 weeks
  • Delivered ready for installation

Configure Radiator

Grace 6 Column 485mm, 7 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 485mm
(D) Depth 254mm
(L) Length 451mm
(PC) Pipe centres 541mm
(TS) Total space required 631mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 622 Watts
Empty weight 48kg
Internal volume 0 L
Delivery 1 piece
Maximum operating pressure 0
Weight 48 kg
Dimensions 451 × 254 × 485 mm
Number of sections

7

Internal volume

5.95

Length (mm)

451

Certification

EN442

Height (mm)

485

Construction material

Cast iron

Depth (mm)

254

Made in

England

Heat output (ΔT50) Watts

622

Heat Output (ΔT50) BTUs

2121

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1090_g6c_485
