Grace 4 Column 660mm, 16 sections

From: £872.40

  • 660mm tall, 993mm long, 175mm deep.
  • Heat output (ΔT50): 1365 Watts
  • Heat output (ΔT50): 4657 BTUs
  • Weight: 85 kg
  • Guarantee: 10 years
  • Delivered in: 6 weeks
  • Delivered ready for installation

Configure Radiator

Grace 4 Column 660mm, 16 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height 660mm
(D) Depth 175mm
(L) Length 993mm
(PC) Pipe centres 1083mm
(TS) Total space required 1173mm
Open pipe centre measurements document for more information.
Heat output (ΔT50) 1365 Watts
Empty weight 85kg
Internal volume 0 L
Delivery 1 piece
Maximum operating pressure 0
Weight 85.0 kg
Dimensions 993 × 175 × 660 mm
Number of sections

16

Internal volume

13.6

Length (mm)

993

Certification

EN442

Height (mm)

660

Construction material

Cast iron

Depth (mm)

175

Made in

England

Heat output (ΔT50) Watts

1365

Heat output (ΔT50) BTUs

4657

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1087_g4c_660
