Grace 2 Column 1040mm, 26 sections

From: £1,435.20

  • 1040mm tall, 1595mm long, 89mm deep.
  • Heat output (ΔT50): 2140 Watts
  • Heat output (ΔT50): 7301 BTUs
  • Weight: 130 kg
  • Guarantee: 10 years
  • Delivered in: 6 weeks
  • Delivered in 2 pieces for partial home assembly. You will need to hire an Assembly Toolkit with purchase of this radiator.

Configure Radiator

Grace 2 Column 1040mm, 26 sections

Description
Additional information
Product files

Grace striking design sits well in both modern and period properties. Its inclined feet and prominent outer ridge adds gravity to an industrial appearance, but is easily softened in an interior with the use of complementary colors.

Radiator drawing
(H) Height mm
(D) Depth mm
(L) Length mm
(PC) Pipe centres
(TS) Total space required
Open pipe centre measurements document for more information.
Heat output (ΔT50) Watts
Empty weight
Internal volume L
Delivery 1 piece
Maximum operating pressure
Weight 130.0 kg
Dimensions 1595 × 89 × 1040 mm
Number of sections

26

Internal volume

20.8

Length (mm)

1595

Certification

EN442

Height (mm)

1040

Construction material

Cast iron

Depth (mm)

89

Made in

England

Heat output (ΔT50) Watts

2140

Heat output (ΔT50) BTUs

7301

Maximum operating temperature

95°C for hot water systems

Maximum operating pressure

8 bar

Bleed valve included

Brass or Nickel

Connections

½" BSP as standard

Pipe centres Open document
Declaration of Performance dop-202009-1081_g2c_1040
